High Energy Hybrid Tantalum Capacitors|CBEB
FEATURES
Tantalum case, Hermetically Sealed, Cylindrical, Radial-lead, Heteropolarity
Commingled by Electrolytic Tantalum Capacitor and Electrochemical Capacitor, Small size, Super Capacitance.
Stable in Electrical Performances, High Reliability, Long life-span, Maximum in the Density of Capacitance is higher than CBEB series.
Built-in as battery in Energy-conversed-circuit & Power-pulsed-circuit, functioned as filtering, storage energy, time-delay circuit.
Tantalum case, Hermetically Sealed, Cylindrical, Radial-lead, Heteropolarity
Commingled by Electrolytic Tantalum Capacitor and Electrochemical Capacitor, Small size, Super Capacitance.
Stable in Electrical Performances, High Reliability, Long life-span, Maximum in the Density of Capacitance is higher than CBEB series.
Built-in as battery in Energy-conversed-circuit & Power-pulsed-circuit, functioned as filtering, storage energy, time-delay circuit.
SPECIFICATIONS
Operating Temperature:-55℃ to +125℃ (to +125℃, with rated voltage derating)
Storage Temperature:-62℃ ~ +130℃
Capacitance Tolerance:Q: (-10%~+30%), K: (±10%), M: (±20%)
Dimensions (unit: mm)
Note
Please do not use multimeter through the measuring procedures (may cause irreversible damage and lead to discard). Capacitance and DF measured at 100Hz, U_=2.200 V, U =1.00- V Test only applied in series equivalent circuit.
Voltage derating is applied at +125℃. (The DCL parameter should be read after 5 minutes when it connected to the circuit).
Special size and demand could consult with us.
