Uncoated Stacked Metallized Polyester Film Capacitor | CDFA
F E A T U R E S :
- Uncoated, stackedconstruction
- Smallsize
- Applied to DC impulse and pulsecircuits
FEATURES
Reference Standard:GB7332(IEC 60384-2)
Climatic Category:55/100/56
RatedTemperature:85 ℃ for V R (DC) 75℃ for V R (AC)
OperatingTemperature Range:
(+85℃ to +105℃: decreasing factor 1.25% per ℃ forV R (DC)
(+75℃ to +105℃: decreasing factor 1.35% per ℃ for V R (AC)
Rated Voltage: 63V 1J, 100V 2A, 250V 2E, 400V 2G, 630V 2J, 1000V 3A
Capacitance Range:0.0010µF ~ 33µF
CapacitanceTolerance:±5%(J), ±10%(K), ±20%(M)
PART NUMBER EXAMPLE
Outline Drawing
INTRODUCTION
◆Uncoated, stacked construction
◆Small size
◆Applied to DC impulse and pulse circuits
