Trimmer Capacitor | 3MM SMD |CHAA

FEATURES

Ultra miniature size with external dimensions of 3.2(W) x 4.5(L) x 1.5(T)mm

Designed for reflow soldering Lowest capacitance drift

Very good Q and high resonant frequency Color coded case permits easy identification

Sealed construction prevents the penetration of Flux and Dust

Chip Trimmer Capacitors, CHAA Series, are miniature and ultra-thin type surface mounting device, and are recommended for miniaturization of electronic equipment.

The capacity drift after adjustment is very low and having a very thin dustproof structure, these capacitors are most suited to the fine adjustment of items.

The plastic is a high temperature liquid-crystal polymer with low dielectric loss and good

mechanical strength.

Note: Specification are subject to change without notice. For more detail and update, please visit our website.

INTRODUCTION
Chip Trimmer Capacitors, CHAA Series, are miniature and ultra-thin type surface mounting
device, and are recommended for miniaturization of electronic equipment.
The capacity drift after adjustment is very low and having a very thin dustproof structure,
these capacitors are most suited to the fine adjustment of items.
The plastic is a high temperature liquid-crystal
polymer with low dielectric loss and good
mechanical strength.
