High Temperature Tantalum Capacitors 155℃|CBGW
CHARACTERs AND SEE
●Equative CA501S
●Silver case, gas seal, Cylindrical, Axial leads, High temperature sleeve, Polar
●Good electric performance, High reliability, long life, Low DF and LC.
●High temperature performance, Can use at 155 ℃
●Suit for oil drilling deep well measurements and high temperatureelectronic devices DC or pulse circuit
●1mplementation of standards: QJ/PWV220-2008
TechnicaI Performance
●Operation temperature:-55℃~+155℃
●Capacitance Tolerance:±10%;±20%;-10%~+30%
●Dissipation Factor:25℃,100Hz (see table 2)
●Leakage Current:25℃ 1O≤0.002 CRUR(uA）or 2uA (whichever is greater)
155℃ 1O≤0.02 CRUR(uA）or 20uA (whichever is greater)
Feature
