Ceramic Trimmer Capacitor | 5MM | CHBA
As well as applications to small sized electronic apparatus, this series is designed for easy handing.
• Wide mounting sizes and variable adjustment available
• Lots of capacity ranges, 3pF through 90pF
• Sturdy mechanical structure against vibration or shock
• Wide mounting sizes and variable adjustment available
• Lots of capacity ranges, 3pF through 90pF
• Sturdy mechanical structure against vibration or shock
FEATURES
As well as applications to small sized electronic apparatus, this series is designed for easy handing.
•Wide mounting sizes and variable adjustment available
•Lots of capacity ranges, 3pF through 90pF
•Sturdy mechanical structure against vibration or shock
SPECIFICATIONS
| OPERATING TEMPERATURE RANGE | -30℃ to +85℃ |
| RATED WORKING VOLTAGE | 100VDC |
| WITHSTANDING VOLTAGE | 400VDC |
| INSULATION RESISTANCE | 104 MΩ min. |
| ROTATION TORQUE | 35 to 200 g-cm |
| SOLDERING TEMPERATURE | 260 ± 5℃ |
NORMAL TYPE
INTRODUCTION
As well as applications tosmall sized electronic apparatus, this series is designed for easy handing.
• Wide mounting sizes and variable adjustment available
• Lots of capacityranges, 3pFthrough 90pF
• Sturdy mechanical structure against vibration or shock
