MLCC brief of technology & process Local enterprises, Japan and Taiwan background The MLCC entrepreneurial team comes from Taiwan Guoji, Huake, Housheng, Dafang and other well-known enterpris es in the same industry. The product manager has been in Guoju for 7 years and Dafang for 12 years, and the fo under is from the senior…
MTBF test report of tantalum capacitor for avionics & defense Jinpei had successfully R&D strictest & NASA military grade the CBFBseries tantalum capacitor that match MTBF test for filter application on military field Jinpei Brand Hermetic seal non-solid axial leads tantalum capacitor-CBFBA887M2AT4(880uF 100V) alternative Evans HC4D100881S,Vishay STE series Electrical parameters after MTBF test as below:…
Jinpei Military grade tantalum capacitor series comparation with the brand of KEMET AVX VISHAY EVANS…… Design for segment market in telecommunication, automotive, military, drill application. Advance material Technology & process for strictest condition lowest ESR saving weight & space
Wet Tantalum Capacitor With Multiple Anodes an anode pack housed within the casing and comprising more than one anode,pellets of anode active material electrically connected to each other by a bridge, and a cathode comprised of cathode current collectors including major faces with cathode active material provided thereupon is described. The bridge, which spans between…
Jinpei CBFB satisfy USA MIL standard of PRF－39006/25CLR81, CBFB has perfectly replaced Vishay STE、ST 93026 etc. series & KEMET T191 T195 T291 T295 etc. which applied in aerospace industry. Jinpei Brand Hermetic seal non-solid axial leads tantalum capacitor-CBFBA887M2AT4(880uF 100V) alternative Evans HC4D100881S,Vishay STE
Jinpei supercapacitor module use on telecom equipment Jinpei Part Number CEDC056136M Application area 48V | Maximum charging voltage 58.8V | Minimum discharge voltage 42V; Maximum continuous charging current 52 Amp | Maximum continuous discharge current 52 Amp; Energy storage requirements 1500 Wh; Working condition Temperature 16-50℃ Humidity 60-90 RH; Cycle Life over 30 years …
Performance Test For 1812 Y5V 10uF +80-20% 50V Jinpei part number CCAA1812F106Z1HT MLCC | multilayer ceramic chip capacitor
Collapsible Supercapacitors If the battery is stored energy marathon runners in the world, so the super capacitor can be compared to a sprinter: super capacitor is more suitable for short-term storage energy applications, but long term battery is a better choice.Now engineers from Georgia tech and the university of South Korea have developed a new supercapacitor designed…
AEC-Q200 measure condition for capacitors Note: The environmental test conditions of the AEC-Q200 are mainly based on the MIL-STD-202 and JEDEC22A-104 specifications. The test temperatures of different parts are not only the same, but also the power supply (voltage, current, and load) requirements. It will be different, high temperature storage is not applied bias and…
