| غرض | characteristic | |||
| نطاق الحرارة الشغالة | -55℃ ~ + 105 ℃ | |||
| Rated operating voltage range | 35V ~ 100V | |||
| Nominal capacitance (25° C, 120هرتز) | 4.7μF ~ 2200 درجة فهرنهايت | |||
| Allowable deviation of nominal
السعة (25° C, 120هرتز) |
M（±20% ） | |||
| DC leakage current（25℃，2min）*1 | I≤0.02CRUR（μA）
سجل تجاري: Nominal capacitance (μF); أور: الفولطية (V) |
|||
| فقدان الظل (الأعلى) (25° C, 120هرتز) | For details, please refer to the “List of Product Specifications and Technical
العوامل” |
|||
| ESR（max）（25℃，100KHz）*2 | For details, please refer to the “List of Product Specifications and Technical
العوامل” |
|||
| High and low temperature characteristics
(impedance ratio, 100كيلوهرتز) |
-55° C: Z-55°C /Z+25°C≤1.25;105° C:Z105°C/ Z+25°C≤1.25 | |||
|
Durability (High Temperature Test) |
The rated voltage is applied at 105°C for 2000h, and after recovery for 24h, the electrical performance of the rated voltage (25°C±5°C) is tested at room
درجة الحرارة |
|||
| Rate of change in capacitance | ≤± 20% of the initial measurement | |||
| The loss angle is tangent | ≤ 150% of the initial measurement | |||
| DC leakage current | ≤ initial prescriptive value | |||
| ESR | ≤ 150% of the initial measurement | |||
|
Steady-state damp heat |
60 ° C, 90~95%RH storage for 1000h, recovery for 24h, room temperature
(25±5 °C) test, its electrical performance confo rms: |
|||
| Rate of change in capacitance | ≤± 20% of the initial measurement | |||
| The loss angle is tangent | ≤ 150% of the initial specified value | |||
| DC leakage current | ≤ initial prescriptive value | |||
| ESR | ≤ 150% of the initial specified value | |||
المميزات
◆ 105 ° C, 1000 ساعات أكد.
◆ حجم قياسي مصغرة الصغيرة مع ارتفاع 5MM.
◆ بنفايات الامتثال
